It’s simple. If we can’t change our economic system, our number’s up

30 04 2017

I occasionally publish articles by George monbiot. At times I have labelled them ‘Monbiot at his best’, even if I disagreed with bits of it….. but this time, he utterly nails it. There’s very little regulars to this site will learn from this, but it is a good piece of writing, and it needs to be shared far and wide, because we truly need this revolution. It’s two years old, but even more relevant now than when he wrote it.

Found on the Guardian’s website…..

'The mother narrative to all this is carbon-fuelled expansion. Our ideologies are mere subplots.'
‘The mother narrative to all this is carbon-fuelled expansion. Our ideologies are mere subplots.’ Photograph: Alamy

Let us imagine that in 3030BC the total possessions of the people of Egypt filled one cubic metre. Let us propose that these possessions grew by 4.5% a year. How big would that stash have been by the Battle of Actium in 30BC? This is the calculation performed by the investment banker Jeremy Grantham.

Go on, take a guess. Ten times the size of the pyramids? All the sand in the Sahara? The Atlantic ocean? The volume of the planet? A little more? It’s 2.5 billion billion solar systems. It does not take you long, pondering this outcome, to reach the paradoxical position that salvation lies in collapse.

To succeed is to destroy ourselves. To fail is to destroy ourselves. That is the bind we have created. Ignore if you must climate change, biodiversity collapse, the depletion of water, soil, minerals, oil; even if all these issues miraculously vanished, the mathematics of compound growth make continuity impossible.

Economic growth is an artefact of the use of fossil fuels. Before large amounts of coal were extracted, every upswing in industrial production would be met with a downswing in agricultural production, as the charcoal or horse power required by industry reduced the land available for growing food. Every prior industrial revolution collapsed, as growth could not be sustained. But coal broke this cycle and enabled – for a few hundred years – the phenomenon we now call sustained growth.

It was neither capitalism nor communism that made possible the progress and pathologies (total war, the unprecedented concentration of global wealth, planetary destruction) of the modern age. It was coal, followed by oil and gas. The meta-trend, the mother narrative, is carbon-fuelled expansion. Our ideologies are mere subplots. Now, with the accessible reserves exhausted, we must ransack the hidden corners of the planet to sustain our impossible proposition.

On Friday, a few days after scientists announced that the collapse of the west Antarctic ice sheet is now inevitable, the Ecuadorean government decided toallow oil drilling in the heart of the Yasuni national park. It had made an offer to other governments: if they gave it half the value of the oil in that part of the park, it would leave the stuff in the ground. You could see this as either blackmail or fair trade. Ecuador is poor, its oil deposits are rich. Why, the government argued, should it leave them untouched without compensation when everyone else is drilling down to the inner circle of hell? It asked for $3.6bn and received $13m. The result is that Petroamazonas, a company with a colourful record of destruction and spills, will now enter one of the most biodiverse places on the planet, in which a hectare of rainforest is said to contain more species than exist in the entire continent of North America.

Almost 45% of the Yasuni national park is overlapped by oil concessions.
Yasuni national park. Murray Cooper/Minden Pictures/Corbis

The UK oil firm Soco is now hoping to penetrate Africa’s oldest national park, Virunga, in the Democratic Republic of Congo; one of the last strongholds of the mountain gorilla and the okapi, of chimpanzees and forest elephants. In Britain, where a possible 4.4 billion barrels of shale oil has just been identified in the south-east, the government fantasises about turning the leafy suburbs into a new Niger delta. To this end it’s changing the trespass laws to enable drilling without consent and offering lavish bribes to local people. These new reserves solve nothing. They do not end our hunger for resources; they exacerbate it.

Look at the lives of the super-rich, who set the pace for global consumption. Are their yachts getting smaller? Their houses? Their artworks? Their purchase of rare woods, rare fish, rare stone? Those with the means buy ever bigger houses to store the growing stash of stuff they will not live long enough to use. By unremarked accretions, ever more of the surface of the planet is used to extract, manufacture and store things we don’t need. Perhaps it’s unsurprising that fantasies about colonising space – which tell us we can export our problems instead of solving them – have resurfaced.

As the philosopher Michael Rowan points out, the inevitabilities of compound growth mean that if last year’s predicted global growth rate for 2014 (3.1%) is sustained, even if we miraculously reduced the consumption of raw materials by 90%, we delay the inevitable by just 75 years. Efficiency solves nothing while growth continues.

The inescapable failure of a society built upon growth and its destruction of the Earth’s living systems are the overwhelming facts of our existence. As a result, they are mentioned almost nowhere. They are the 21st century’s great taboo, the subjects guaranteed to alienate your friends and neighbours. We live as if trapped inside a Sunday supplement: obsessed with fame, fashion and the three dreary staples of middle-class conversation: recipes, renovations and resorts. Anything but the topic that demands our attention.

Statements of the bleeding obvious, the outcomes of basic arithmetic, are treated as exotic and unpardonable distractions, while the impossible proposition by which we live is regarded as so sane and normal and unremarkable that it isn’t worthy of mention. That’s how you measure the depth of this problem: by our inability even to discuss it.

Advertisements




Concentrated solar power in the USA: a performance review

26 04 2017

I have written before about the concentrated solar power stations in the US beforehere. Roger Andrews (put glasses on him, and he looks just like me!) has just written a damning exposé on the excellent Energy Matters website you should all be following too……. can I say “I rest my case”?



~~~~~~~~~~~~~~~~~~~~~~~~~~~~

A review of concentrated solar power (CSP) plants operating in the US reveals that they are costly, heavily-subsidized, generally performing below expectations and no more efficient than utility-scale PV plants. The need to jump-start them in the morning can also require the burning of substantial quantities of natural gas. And although CSP’s sole advantage over PV is that it can store energy for re-use only one of the plants considered has built-in storage capacity. As discussed in the earlier concentrated solar power in Spain post , however, it is unlikely that enough storage could be installed at a CSP plant to provide more than short-term load-following capability when the sun is not shining. (Inset: Ivanpah Unit 2 tower catches fire, May 2016).

This review originated from a comment posted by correspondent “Thinks Too Much” (T2M) on the Blowout Week 172 thread which bewailed the lack of publicity being given to the poor performance of the Crescent Dunes CSP plant. After further exchanges T2M sent me a copy of a spreadsheet he had painstakingly constructed from the EIA’s Electricity Browser monthly data, which, supplemented by Wikipedia data on the Genesis plant I have used to develop the data presented here. So a thank you and a hat tip to T2M.

The locations of the six CSP plants reviewed (Mojave, Solana, Genesis and the three units at Ivanpah – Crescent Dunes is discussed later) are shown in Figure 1. Installed capacities are Mojave 250 MWe, Solana 250 MWe, Genesis 250MWe and Ivanpah 392 MWe (126 + 126 + 133). Nameplate capacities (MWp) are about 10% higher. Only the Solana plant has storage capability (reported to be 1.68GWh), but no details are available on its performance. Mojave, Genesis and Solana are “parabolic trough” plants and Ivanpah and Crescent Dunes “solar tower” plants. Additional details on CSP plant design are given in the “concentrated solar power in Spain” post post linked to in the introduction.

Figure 1: Plant location map

All plants except Crescent Dunes have monthly production data for the two-year period from January 2015 through December 2016. Over this two-year period Solana generated 1,363GWh, Ivanpah 1,355GWh, Mojave 1,128GWh and Genesis 1,246GWh, for a total of 5,092GWh. This represents less than 1% of the electricity consumed in Arizona, Nevada and Southern California in 2015 and 2016.

A plot of monthly generation from the plants is not very instructive, so we begin instead with a plot of capacity factors. Figure 2 shows average capacity factors by month. Solana leads with an average of 31.1%, followed by Genesis with 28.4%, Mojave with 25.7% and Ivanpah with 19.7%. The weighted average capacity factor for all four plants is 25.4% (calculated using MWe; calculated using MWp it’s around 23%). This, however, is not significantly higher than the capacity factors achieved at conventional utility-scale PV plants in the Southwest US. According to the EIA data I reviewed in solar capacity factors in the US, which yielded values of 28.7% in California, 27.0% in Arizona and 26.7% in Nevada, it is in fact lower:

Figure 2: Monthly capacity factors

A question that arises here is why CSP plants located in the same desert environment don’t give more consistent results. The most likely reason is malfunctions in plant operation, with the Ivanpah plant the most seriously affected. Figure 3 plots capacity factors for the three Ivanpah units:

Figure 3: Monthly capacity factors for Ivanpah Units 1, 2 and 3

The three Ivanpah units cover an area of only about 10sq km, so there is no meteorological reason why any one unit should outperform any other – so long as the units are working properly. But they generate comparable amounts of electricity only about half the time. There are large discrepancies in early 2015 and also between April and June 2016 (partially but not entirely explained by the Unit 2 tower catching fire in May, a result of misaligned mirrors). Other features of Figure 3 are also not credible, such as higher solar generation in February 2016 than in May 2015. Seasonal variations are less pronounced and more erratic than one would expect from a properly-functioning solar plant, and the capacity factors (21.1% for Unit 1, 17.9% for Unit 2 and 20.2% for Unit 3) also seem implausibly low. The implication is that the Ivanpah plant is not working as planned, with problems both in the solar side of the operation and probably also in the power generation circuit, which is a complicated system that uses heat exchangers to produce the steam that drives the generators from the molten salt.

Problems with Ivanpah operations other than the May 2016 fire have also been reported by the media:

Wired Magazine: Ivanpah initially struggled to fulfill its electricity contract, and it would have had to shut down if the California Public Utilities Commission didn’t throw it a bone this past March, approving without discussion  agreements that would give the owners of the plant, NRG Energy, BrightSource Energy and Alphabet’s Google, up to a year to work out the problems.

Wikipedia: In November 2014, Associated Press reported that the plant was producing only “about half of its expected annual output”. The California Energy Commission issued a statement blaming this on “clouds, jet contrails and weather”. Performance improved considerably in 2015 — to about 650 GWh, but ownership partner NRG Energy said in its November quarterly report that Ivanpah would likely not meet its contractual obligations to provide power to PG&E during the year, raising the risk of default on its Power Purchase Agreement.

Greentechmedia: The (Ivanpah) plant….. kicked off commercial operation at the tail end of December 2013, and for the eight-month period from January through August, its three units generated 254,263 megawatt-hours of electricity, according to U.S. Energy Information Administration data. That’s roughly one-quarter of the annual 1 million-plus megawatt-hours that had been anticipated. Output did pick up in the typically sunny months of May, June, July and August, as one might expect, with 189,156 MWh generated in that four-month period. But even that higher production rate would translate to annual electricity output of less than 600,000 MWh, at least 40 percent below target.

Even Solana, the best-performing of the plants, had its problems:

Phoenix New Times: (Solana) was knocked out by a microburst for a few days in late July and won’t generate power normally for months, a new report reveals. The severe problem comes on top of generally poor performance from the $2 billion project over the past two years. As New Times reported in November 2014, in its first year the plant produced only about two-thirds of the power that its former owner, Spain’s Abengoa Solar, said it would. The company and Arizona Public Service, which is contracted to buy the electricity the plant generates, said at the time that performance would improve. Publicly available production figures reviewed by New Times this week showed that Solana did generate more electricity in its second year but is still well below its advertised potential. The plant also did worse in the second quarter of 2016 than it did in the same period in 2015, the numbers show. And considering the new report on the July microburst, the plant’s third-quarter results for this year — which haven’t been released yet — are likely to be abysmal.

(Note that Figure 2 confirms a large drop in capacity factor between July and August 2016.)

No specific malfunctions have been reported at Mojave or Genesis, but the fact that the capacity factors at these plants are lower than at Solana suggest that they also had their share of them.

Next on the agenda comes natural gas. The Genesis, Solana and Ivanpah plants (but not Mojave) need to burn it to get the plant warmed up in the morning. Again this is a particular problem at Ivanpah:

Wikipedia: The plant requires burning natural gas each morning to get the plant started. The Wall Street Journal reported: “Instead of ramping up the plant each day before sunrise by burning one hour’s worth of natural gas to generate steam, Ivanpah needs more than four times that much.” On August 27, 2014, the State of California approved Ivanpah to increase its annual natural gas consumption from 328 million cubic feet of natural gas, as previously approved, to 525 million cubic feet. In 2014, the plant burned 867,740 million BTU of natural gas emitting 46,084 metric tons of carbon dioxide, which is nearly twice the pollution threshold at which power plants and factories in California are required to participate in the state’s cap and trade program to reduce carbon emissions.

How much natural gas is actually consumed in the warm-up process? According to T2M’s spreadsheet Ivanpah consumed 1.29 trillion btu in 2016. If this much natural gas had been consumed in a typical CCGT plant (heat factor 7,650 btu/kWh according to EIA) it would have generated 169GW, almost a quarter of the 703GWh of solar electricity Ivanpah generated in that year.

And as shown in Figure 4 there is a fairly strong correlation between the amount of gas Ivanpah burns and the amount of solar generated (R^2 = 0.51). Clearly the more gas the plant burns in the morning the more solar energy it generates later in the day. (Although it’s only fair to note, as the WSJ reports, that Ivanpah is a particularly bad example. As far as I have been able to determine Genesis and Solana burn significantly less gas.)

Figure 4: Natural gas consumption vs. solar generation in 2016, Ivanpah Units 1, 2 and 3, monthly data

Last but one on the agenda is the question of project costs. Based on data from a number of sources, not all of which are necessarily reliable, I have put together the following table. It contains Crescent Dunes for completeness:

The five listed plants, which between them generate less than 1% of the electricity consumed in Arizona, Nevada and Southern California, cost over $8 billion to construct, and over 70% of this cost was covered by federal loan guarantees. All of the projects were also eligible for a 30% federal tax credit. With these generous subsidies and a bit of creative wheeling and dealing it might well have been possible for the developers to complete construction without forking out any of their own money at all.

Of particular interest is the ~$6,430/kW installed cost, which is in the same range as the 3.2GW Hinkley Point C nuclear plant. According to NREL’s 2015 cost estimates it also exceeds the cost of installing the same amount of utility-scale PV capacity by a factor of over three.

Another consideration is electricity sales price. Electricity from the plants is sold to various Southwest US utilities at cents/kWh rates and reliable data are again hard to come by, but the following numbers indicate a range of between 12 and 20c/kWh, or $120-200/MWh:

These rates equal or exceed the all-sector rates that local utilities charge in Arizona and Nevada, which according to EIA data are presently 9.62c/kWh and 8.02c/kWh respectively. After addition of transmission charges, administrative charges, taxes etc. Arizona and Nevada utilities will therefore lose money on each kWh of CSP energy they buy. With the all-sector rate at 15.02 c/kWh California utilities will probably lose money too, although not so much. And ultimately the consumer will finish up paying.

Last on the agenda is Crescent Dunes, the project that gave birth to this post. As shown in Figure 5, Crescent Dunes started operations in October 2015 and took its time ramping up, but by the late summer of 2016 it was achieving respectable capacity factors of between 30 and 40%. But then in early October a leak developed in the molten salt circuit and the plant was shut down, and it has stayed shut down in the five months since (probably now for six months. On March 2 of this year it was expected that it would be “another few weeks” before operations recommenced. But as of the time of writing there are no reports of the plant restarting, so presumably it’s still down):

Figure 5: Monthly capacity factors since startup, Crescent Dunes

Now there’s nothing unusual about a power plant shutting down, but it’s not often that a “low-tech maintenance issue” shuts one down for six months:

PV Times, March 2, 2017:  “We expect to be back online in a few weeks,” CEO Kevin B. Smith said. A hot salt tank issue “took a while to get it fixed, but it’s a pretty low-tech issue,” Smith said …… I understand you guys have got to figure out what’s going on, but you just seem so infatuated with this hot salt tank issue. It’s a maintenance issue ….”

One has to wonder how long a real breakdown might shut the plant down for.





Life in a ‘degrowth’ economy, and why you might actually enjoy it

23 04 2017

V8gsgy6r 1412143664
Time to get off the economic growth train?
Sergey Nivens/Shutterstock

Samuel Alexander, University of Melbourne

What does genuine economic progress look like? The orthodox answer is that a bigger economy is always better, but this idea is increasingly strained by the knowledge that, on a finite planet, the economy can’t grow for ever. The Conversation

This week’s Addicted to Growth conference in Sydney is exploring how to move beyond growth economics and towards a “steady-state” economy.

But what is a steady-state economy? Why it is it desirable or necessary? And what would it be like to live in?

The global predicament

We used to live on a planet that was relatively empty of humans; today it is full to overflowing, with more people consuming more resources. We would need one and a half Earths to sustain the existing economy into the future. Every year this ecological overshoot continues, the foundations of our existence, and that of other species, are undermined.

At the same time, there are great multitudes around the world who are, by any humane standard, under-consuming, and the humanitarian challenge of eliminating global poverty is likely to increase the burden on ecosystems still further.

Meanwhile the population is set to hit 11 billion this century. Despite this, the richest nations still seek to grow their economies without apparent limit.

Like a snake eating its own tail, our growth-orientated civilisation suffers from the delusion that there are no environmental limits to growth. But rethinking growth in an age of limits cannot be avoided. The only question is whether it will be by design or disaster.

Degrowth to a steady-state economy

The idea of the steady-state economy presents us with an alternative. This term is somewhat misleading, however, because it suggests that we simply need to maintain the size of the existing economy and stop seeking further growth.

But given the extent of ecological overshoot – and bearing in mind that the poorest nations still need some room to develop their economies and allow the poorest billions to attain a dignified level of existence – the transition will require the richest nations to downscale radically their resource and energy demands.

This realisation has given rise to calls for economic “degrowth”. To be distinguished from recession, degrowth means a phase of planned and equitable economic contraction in the richest nations, eventually reaching a steady state that operates within Earth’s biophysical limits.

In a world of 7.2 billion and counting, we need to think hard about our fair share.
Karpov Oleg/Shutterstock

At this point, mainstream economists will accuse degrowth advocates of misunderstanding the potential of technology, markets, and efficiency gains to “decouple” economic growth from environmental impact. But there is no misunderstanding here. Everyone knows that we could produce and consume more efficiently than we do today. The problem is that efficiency without sufficiency is lost.

Despite decades of extraordinary technological advancement and huge efficiency improvements, the energy and resource demands of the global economy are still increasing. This is because within a growth-orientated economy, efficiency gains tend to be reinvested in more consumption and more growth, rather than in reducing impact.

This is the defining, critical flaw in growth economics: the false assumption that all economies across the globe can continue growing while radically reducing environmental impact to a sustainable level. The extent of decoupling required is simply too great. As we try unsuccessfully to “green” capitalism, we see the face of Gaia vanishing.

The very lifestyles that were once considered the definition of success are now proving to be our greatest failure. Attempting to universalise affluence would be catastrophic. There is absolutely no way that today’s 7.2 billion people could live the Western way of life, let alone the 11 billion expected in the future. Genuine progress now lies beyond growth. Tinkering around the edges of capitalism will not cut it.

We need an alternative.

Enough for everyone, forever

When one first hears calls for degrowth, it is easy to think that this new economic vision must be about hardship and deprivation; that it means going back to the stone age, resigning ourselves to a stagnant culture, or being anti-progress. Not so.

Degrowth would liberate us from the burden of pursuing material excess. We simply don’t need so much stuff – certainly not if it comes at the cost of planetary health, social justice, and personal well-being. Consumerism is a gross failure of imagination, a debilitating addiction that degrades nature and doesn’t even satisfy the universal human craving for meaning.

Do we really need to buy all this stuff anyway?
Radu Bercan/Shutterstock

Degrowth, by contrast, would involve embracing what has been termed the “simpler way” – producing and consuming less.

This would be a way of life based on modest material and energy needs but nevertheless rich in other dimensions – a life of frugal abundance. It is about creating an economy based on sufficiency, knowing how much is enough to live well, and discovering that enough is plenty.

The lifestyle implications of degrowth and sufficiency are far more radical than the “light green” forms of sustainable consumption that are widely discussed today. Turning off the lights, taking shorter showers, and recycling are all necessary parts of what sustainability will require of us, but these measures are far from enough.

But this does not mean we must live a life of painful sacrifice. Most of our basic needs can be met in quite simple and low-impact ways, while maintaining a high quality of life.

What would life be like in a degrowth society?

In a degrowth society we would aspire to localise our economies as far and as appropriately as possible. This would assist with reducing carbon-intensive global trade, while also building resilience in the face of an uncertain and turbulent future.

Through forms of direct or participatory democracy we would organise our economies to ensure that everyone’s basic needs are met, and then redirect our energies away from economic expansion. This would be a relatively low-energy mode of living that ran primarily on renewable energy systems.

Renewable energy cannot sustain an energy-intensive global society of high-end consumers. A degrowth society embraces the necessity of “energy descent”, turning our energy crises into an opportunity for civilisational renewal.

We would tend to reduce our working hours in the formal economy in exchange for more home-production and leisure. We would have less income, but more freedom. Thus, in our simplicity, we would be rich.

Wherever possible, we would grow our own organic food, water our gardens with water tanks, and turn our neighbourhoods into edible landscapes as the Cubans have done in Havana. As my friend Adam Grubb so delightfully declares, we should “eat the suburbs”, while supplementing urban agriculture with food from local farmers’ markets.

Community gardens, like this one in San Francisco, can help achieve sufficiency.
Kevin Krejci/Wikimedia Commons, CC BY

We do not need to purchase so many new clothes. Let us mend or exchange the clothes we have, buy second-hand, or make our own. In a degrowth society, the fashion and marketing industries would quickly wither away. A new aesthetic of sufficiency would develop, where we creatively re-use and refashion the vast existing stock of clothing and materials, and explore less impactful ways of producing new clothes.

We would become radical recyclers and do-it-yourself experts. This would partly be driven by the fact that we would simply be living in an era of relative scarcity, with reduced discretionary income.

But human beings find creative projects fulfilling, and the challenge of building the new world within the shell of the old promises to be immensely meaningful, even if it will also entail times of trial. The apparent scarcity of goods can also be greatly reduced by scaling up the sharing economy, which would also enrich our communities.

One day, we might even live in cob houses that we build ourselves, but over the next few critical decades the fact is that most of us will be living within the poorly designed urban infrastructure that already exists. We are hardly going to knock it all down and start again. Instead, we must ‘retrofit the suburbs’, as leading permaculturalist David Holmgren argues. This would involve doing everything we can to make our homes more energy-efficient, more productive, and probably more densely inhabited.

This is not the eco-future that we are shown in glossy design magazines featuring million-dollar “green homes” that are prohibitively expensive.

Degrowth offers a more humble – and I would say more realistic – vision of a sustainable future.

Making the change

A degrowth transition to a steady-state economy could happen in a variety of ways. But the nature of this alternative vision suggests that the changes will need to be driven from the “bottom up”, rather than imposed from the “top down”.

What I have written above highlights a few of the personal and household aspects of a degrowth society based on sufficiency (for much more detail, see here and here). Meanwhile, the ‘transition towns’ movement shows how whole communities can engage with the idea.

But it is critical to acknowledge the social and structural constraints that currently make it much more difficult than it needs to be to adopt a lifestyle of sustainable consumption. For example, it is hard to drive less in the absence of safe bike lanes and good public transport; it is hard find a work-life balance if access to basic housing burdens us with excessive debt; and it is hard to re-imagine the good life if we are constantly bombarded with advertisements insisting that “nice stuff” is the key to happiness.

Actions at the personal and household levels will never be enough, on their own, to achieve a steady-state economy. We need to create new, post-capitalist structures and systems that promote, rather than inhibit, the simpler way of life. These wider changes will never emerge, however, until we have a culture that demands them. So first and foremost, the revolution that is needed is a revolution in consciousness.

I do not present these ideas under the illusion that they will be readily accepted. The ideology of growth clearly has a firm grip on our society and beyond. Rather, I hold up degrowth up as the most coherent framework for understanding the global predicament and signifying the only desirable way out of it.

The alternative is to consume ourselves to death under the false banner of “green growth”, which would not be smart economics.

Samuel Alexander, Research fellow, Melbourne Sustainable Society Institute, University of Melbourne

This article was originally published on The Conversation. Read the original article.





A good Friday’s pouring…..

22 04 2017

If after finishing digging up the trenches for the retaining wall on Good Friday you had told me they would be full of concrete within a week…. I would have told you that you had sawdust for brains. Yet that is exactly what happened, but you need all your stars lining up.

Image may contain: outdoor

My first four bars…..

The day after the big dig, I excitedly started laying steel bars in the trench, only to quickly realise there was no way known I could do this on my own. I’d lift one end of a 6m long bar to sit it on a chair, then walk to the other end to do the same, and the first end would fall off, entailing walking back and forth so many times that I reckon I’d walked over 150m just to set four bars down! Then, trying to tie the L shaped bars that reinforce the wall to those bars on my own simply proved nigh impossible, I would at least need one person to just hold the bar while I tied….. and being Easter, the chances of anyone helping were very slim indeed….. I started thinking that this job would easily take me a month, and I better get used to the idea.



Monday morning, Caleb, a friend’s teenaged son who lives locally and could use some spare cash, came to help me. Then, out of the blue, this American wwoofer who had contacted me some weeks before but didn’t know when he’d be in Tasmania rings me up, all excited and wanting to get stuck into some construction work…. “Your timing could not be better” I told him, and he was here by lunch time keen and eager. Best of all, he had way more concreting experience than I ever had, and he literally took over, becoming my project manager!

Image may contain: outdoor and nature

Caleb and Nico hard at work tying bars…..

Nico is not only a great concretor, he’s also amazing company, and we’ve been chewing the fat every night over a well-earned cider. How this guy came into my life so unexpectedly just blows me away. Sometimes you’ve just got to get lucky……

Retaining walls work a bit like you standing in a strong wind…… think ‘back to the wind’, and your feet on the ground stopping you falling over. The pressure on your back wants to topple you over, but your toes strain against the wind’s force, all you need is a heel and toe joined to strong enough calf muscles to make sure the whole leg is stiff enough to avoid the embarrassment….. that’s exactly what the L bars do, and the concrete is the muscle.

I then came up with what I can only describe as a brilliant idea. The top of the footing has to have a layer of mesh no more than 50mm from the top surface. How to set this up so you can place it while busily pouring wet concrete? My solution was to tie it to the bars at the right height, and in just three places at the top so that one of us could just run around behind the formwork, cut those ties, and drop the mesh at its lower ‘hinge’. Then all I’d have to do is sink it into the concrete with the vibrator. Worked a treat…..

Image may contain: shoes, sky and outdoor

Formwork in place

Once all the steel was in, the formwork to stop the concrete falling into the drain area had to be put up. I had bought 8’x4′ sheets of formply to cut into 300mm high boards and made a load of pointy timber stakes to hold them up with, but the stakes refused to penetrate the hard clay…  what to do? Nico said, ‘in the states we use metal form spikes’, but I’d never heard of them here. So I rang Nubco where I bought the steel, and they suggested 600mm star pickets that Bunnings sell. Sure enough, Bunnings had a whole lot in store at $5.80 each. I wasn’t keen on either driving that far let alone patronising Bunnings, so as we were approaching Huonville in the ute, I suggested Nico ring Mitre 10 there to see if they had some…. and they did. Not only that, they were on sale for $3.95 each (I needed 60 of them!), and I walked out with a bunch of screws, a new level and heavy hammer for less than what the pickets would have cost at Bunnings.  I’m on a roll!



Before we knew it, it looked very close to the job being finished, and I rang the concrete crowd and ordered the runny stuff…. I still can’t believe it all went so fast.

Image may contain: sky, cloud, ocean, twilight, tree, outdoor, nature and water

Dawn on pouring day……. what a gorgeous start!

We spent Friday morning finishing the formwork, tying up loose ends, adding chairs where necessary, and cleaning all the loose rubbish out of the trenches, which we finished nearly an hour and a half before the first truck arrived..

The whole West wing of the footing was poured from the first truck. The new concrete vibrator I bought myself worked a treat, most of the concrete finding its own level from being quite violently shaken.

The second truck arrived to pour the ‘pointy bit’ in the middle of the house, and that’s where the work on the hottest April day in over 50 years started in earnest….. because the chute was too short to reach, and poor old Nico had to rake and shovel the stuff into the corner while Caleb barrowed concrete from the truck to the edge of the trench, almost losing the wheelbarrow one time when he got too close, and the wheel fell into the wet concrete! Much frantic pulling and pushing from the three of us (while the truck driver never even lifted a finger) got the wheelbarrow back out again, but let me tell you we were all sweating! Swinging the heavy petrol powered vibrator at full arms length was hard yakka, but concrete waits for no man, and there was no stopping. And passing out wasn’t an option either….!

After it was all over, Nico said to me that sometimes you buy something, and you think to yourself, that was a good purchase….. but that concrete vibrator must be the best thing I ever bought according to him!

DSC_2641

All done…… what a job!

Needless to say, $3700 later it all ended well…… but we were all exhausted, and the entire affair reminded me of why I swore I’d never do it again after the last time.

In my last post where I mentioned this, I stated that if I didn’t save myself $10,000 by doing it myself I’d eat my hat. Well, at this stage it looks like I may well save closer to $20,000. Of course we still have to pour the slab over the top of all this work, but it’s hard to imagine how concretors can pay themselves as well as they do all the same…..

Time for a couple of days rest now…….





Charlie Hall on ERoEI

21 04 2017





A good Friday’s digging……

16 04 2017

There must be something in Tasmania’s water that doesn’t agree with the building industry….. I’ve wasted so much time waiting for people to do things for me, it beggars belief. All along, I said that this time, 15 years older and wiser, I would not undertake to do my own concreting at Mon Abri MkII. So I contacted this local contractor, whom everyone around here seems to think is the bee’s knees. He came out, sighted the house site, and the plans, a copy of which he left with. I explained to him what was needed, that I had already ordered the reinforcing, and that all I needed was someone to put it all together……

About a week later, the reo had arrived, and still no quote; so I texted him to tell him the steel was here and asking for his quote. The next day, he rang back with an over the phone quote of $30,000, which I’m almost sure he said included building the block wall… I’m a bit hard of hearing these days, so maybe I got that wrong. In any case, thirty grand being such a very round number, I asked for a written quote. Which took another two weeks. And when it arrived, it was way over the top, with no break down of how much the labour was, or the concrete pumping, earthworks, or anything for that matter, it just lumped everything together, including the steel I already had….. and the quote was now $32,000……. plus $26,000 to build the wall!

I almost fell off my chair…..

That wall building quote works out at $12 a block, which I established was four times the normal rate. So he must have included the cost of the blocks (which set me back $17,000…!) Thirty pallets of blocks is sort of hard to not see….. so what on earth was he thinking about?

20170220_175633

String profiles in place

Then to top it off, I visited my friend Dave who’s building a greenhouse up the hill, and the same contractor stuffed the footings up; they weren’t level, causing the block layer to have to trim as much as an inch off the blocks to make the top of the first course level…… By that stage, there was no doubt I was going to have do the job myself, any confidence I might have had at the start of the process had by now vanished. If I don’t save $10,000 by doing it myself, I’ll eat my (very sweaty) hat…..

Having discussed this with Matt next door – who owns his own excavator – we walked over my site with Steve, a very experienced excavator and crane driver who works in Antarctica – I don’t think they hire dodgy people to work there at great expense – and settled on Good Friday to start digging the retaining wall footings.

I had almost (another) month to psych myself up on how we would do this, set the

20170414_103217

Depth/Width gauge

profiles up to accurately arrive at the house’s footprint, and eventually started painting lines in the dirt. I also made myself a gauge to measure both the depth and the width of the trenches.

Because the previous excavator driver decided to dig a hole in the wrong place last time, and had to refill it to remedy the error, that part of the bank had collapsed in the heavy rain last year, actually making it impossible to place the profiles where I wanted them. So that had to be fixed first, because a whole pile of dirt and rocks was actually right on top of where we had to dig.

20170414_082914

Fixing Trev’s boo boo

20170414_083810

earthmoving ute









Then, because the digger was too far from the bank when digging the small trench under the living space, the spoil had to be put on the ute, which I then had to move and manually unload the two tonnes of dirt with shovel and rake. Like I say, this project will either keep me fit, or kill me..!

20170414_100004

the next pizza oven base..!

There was also a huge rock that had to come out where the slab will be, because the top of it was actually higher than floor level. Trev (the last operator) reckoned his machine couldn’t pull it out, but Matt’s excavator is a newer and better device, and Steve had it out in no time…. it might not look like much in the photo, but it has to weigh close to 500kg, and it’s a great find actually, because it’s (almost) big enough to make the base of the next pizza oven on its own, and it’s nice and flat!

The rest of the digging went well, even though working so close to the embankment made things difficult for Steve, who did a great job. It’s so nice to work with professionals, let me tell you…. Now all I have to do is fill the hole with steel and concrete….

20170414_124353

20170414_124417









Why I am still anti Lithium and EV

13 04 2017

Originally published at Alice Friedemann’s excellent blog, energyskeptic.com/

[This is by far the best paper explaining lithium reserves, lithium chemistry, recycling, political implications, and more. I’ve left out the charts, graphs, references, and much of the text, to see them go to the original paper in the link below.]

~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~

I personally don’t think that electric cars will ever be viable because battery development is too slow, and given that oil can be hundreds of times more energy dense than a battery of the same weight, the laws of physics will prevent them from ever achieving enough energy density — see my post at Who Killed the Electric Car. (and also my more-up-to-date version and utility-scale energy storage batteries in my book When Trains Stop Running: Energy and the Future of Transportation.  Some excerpts from my book about lithium and energy storage:

Li-ion energy storage batteries are more expensive than PbA or NaS, can be charged and discharged only a discrete number of times, can fail or lose capacity if overheated, and the cost of preventing overheating is expensive. Lithium does not grow on trees. The amount of lithium needed for utility-scale storage is likely to deplete known resources (Vazquez, S., et al. 2010. Energy storage systems for transport and grid applications. IEEE Transactions on Industrial Electronics 57(12): 3884).

To provide enough energy for 1 day of storage for the United states, li-ion batteries would cost $11.9 trillion dollars, take up 345 square miles and weigh 74 million tons (DOE/EPRI. 2013. Electricity storage handbook in collaboration with NRECA. USA: Sandia National Laboratories and Electric Power Research Institute)

Barnhart et al. (2013) looked at how much materials and energy it would take to make batteries that could store up to 12 hours of average daily world power demand, 25.3 TWh. Eighteen months of world-wide primary energy production would be needed to mine and manufacture these batteries, and material production limits were reached for many minerals even when energy storage devices got all of the world’s production (with zinc, sodium, and sulfur being the exceptions). Annual production by mass would have to double for lead, triple for lithium, and go up by a factor of 10 or more for cobalt and vanadium, driving up prices. The best to worst in terms of material availability are: CAES, NaS, ZnBr, PbA, PHS, Li-ion, and VRB (Barnhart, C., et al. 2013. On the importance of reducing the energetic and material demands of electrical energy storage. Energy Environment Science 2013(6): 1083–1092). ]

Vikström, H., Davidsson, S., Höök, M. 2013. Lithium availability and future production outlooks. Applied Energy, 110(10): 252-266. 28 pages



Abstract

Lithium is a highly interesting metal, in part due to the increasing interest in lithium-ion batteries. Several recent studies have used different methods to estimate whether the lithium production can meet an increasing demand, especially from the transport sector, where lithium-ion batteries are the most likely technology for electric cars. The reserve and resource estimates of lithium vary greatly between different studies and the question whether the annual production rates of lithium can meet a growing demand is seldom adequately explained. This study presents a review and compilation of recent estimates of quantities of lithium available for exploitation and discusses the uncertainty and differences between these estimates. Also, mathematical curve fitting models are used to estimate possible future annual production rates. This estimation of possible production rates are compared to a potential increased demand of lithium if the International Energy Agency’s Blue Map Scenarios are fulfilled regarding electrification of the car fleet. We find that the availability of lithium could in fact be a problem for fulfilling this scenario if lithium-ion batteries are to be used. This indicates that other battery technologies might have to be implemented for enabling an electrification of road transports.

Highlights:

  • Review of reserves, resources and key properties of 112 lithium deposits
  • Discussions of widely diverging results from recent lithium supply estimates
  • Forecasting future lithium production by resource-constrained models
  • Exploring implications for future deployment of electric cars

Introduction

Global transportation mainly relies on one single fossil resource, namely petroleum, which supplies 95% of the total energy [1]. In fact, about 62% of all world oil consumption takes place in the transport sector [2]. Oil prices have oscillated dramatically over the last few years, and the price of oil reached $100 per barrel in January 2008, before skyrocketing to nearly $150/barrel in July 2008. A dramatic price collapse followed in late 2008, but oil prices have at present time returned to over $100/barrel. Also, peak oil concerns, resulting in imminent oil production limitations, have been voiced by various studies [3–6].

It has been found that continued oil dependence is environmentally, economically and socially unsustainable [7].

The price uncertainty and decreasing supply might result in severe challenges for different transporters. Nygren et al. [8] showed that even the most optimistic oil production forecasts implied pessimistic futures for the aviation industry. Curtis [9] found that globalization may be undermined by peak oil’s effect on transportation costs and reliability of freight.

Barely 2% of the world electricity is used by transportation [2], where most of this is made up by trains, trams, and trolley buses.

A high future demand of Li for battery applications may arise if society choses to employ Li-ion technologies for a decarbonization of the road transport sector.

Batteries are at present time the second most common use, but are increasing rapidly as the use of li-ion batteries for portable electronics [12], as well as electric and hybrid cars, are becoming more frequent. For example, the lithium consumption for batteries in the U.S increased with 194 % from 2005 to 2010 [12]. Relatively few academic studies have focused on the very abundance of raw materials needed to supply a potential increase in Li demand from transport sector [13]. Lithium demand is growing and it is important to investigate whether this could lead to a shortfall in the future.



[My comment: utility scale energy storage batteries in commercial production are lithium, and if this continues, this sector alone would quickly consume all available lithium supplies: see Barnhart, C., et al. 2013. On the importance of reducing the energetic and material demands of electrical energy storage. Energy Environment Science 2013(6): 1083–1092.]

Aim of this study

Recently, a number of studies have investigated future supply prospects for lithium [13–16]. However, these studies reach widely different results in terms of available quantities, possible production trajectories, as well as expected future demand. The most striking difference is perhaps the widely different estimates for available resources and reserves, where different numbers of deposits are included and different types of resources are assessed. It has been suggested that mineral resources will be a future constraint for society [17], but a great deal of this debate is often spent on the concept of geological availability, which can be presented as the size of the tank. What is frequently not reflected upon is that society can only use the quantities that can be extracted at a certain pace and be delivered to consumers by mining operations, which can be described as the tap. The key concept here is that the size of the tank and the size of the tap are two fundamentally different things.

This study attempts to present a comprehensive review of known lithium deposits and their estimated quantities of lithium available for exploitation and discuss the uncertainty and differences among published studies, in order to bring clarity to the subject. The estimated reserves are then used as a constraint in a model of possible future production of lithium and the results of the model are compared to possible future demand from an electrification of the car fleet. The forecasts are based on open, public data and should be used for estimating long term growth and trends. This is not a substitute for economical short-term prognoses, but rather a complementary vision.

Data sources

The United States Geological Survey (USGS) has been particularly useful for obtaining production data series, but also the Swedish Geological Survey (SGU) and the British Geological Survey (BGS) deserves honourable mention for providing useful material. Kushnir and Sandén [18], Tahil [19, 20] along with many other recent lithium works have also been useful. Kesler et al. [21] helped to provide a broad overview of general lithium geology.

Information on individual lithium deposits has been compiled from numerous sources, primarily building on the tables found in [13–16]. In addition, several specialized articles about individual deposits have been used, for instance [22–26]. Public industry reports and annual yearbooks from mining operators and lithium producers, such as SQM [27], Roskill [28] or Talison Lithium [29], also helped to create a holistic data base.

In this study, we collected information on global lithium deposits. Country of occurrence, deposit type, main mineral, and lithium content were gathered as well as published estimates for reserves and resources. Some deposits had detailed data available for all parameters, while others had very little information available. Widely diverging estimates for reserves and resources could sometimes be found for the same deposit, and in such cases the full interval between the minimum and maximum estimates is presented. Deposits without reserve or resource estimates are included in the data set, but do not contribute to the total. Only available data and information that could be found in the public and academic spheres were compiled in this study. It is likely that undisclosed and/or proprietary data could contribute to the world’s lithium volume but due to data availability no conclusions on to which extent could be made.

Geological overview

In order to properly estimate global lithium availability, and a feasible reserve estimate for modelling future production, this section presents an overview of lithium geology. Lithium is named after the Greek word “lithos” meaning “stone”, represented by the symbol Li and has the atomic number 3. Under standard conditions, lithium is the lightest metal and the least dense solid element. Lithium is a soft, silver-white metal that belongs to the alkali group of elements.

As all alkali elements, Li is highly reactive and flammable. For this reason, it never occurs freely in nature and only appears in compounds, usually ionic compounds. The nuclear properties of Li are peculiar since its nuclei verge on instability and two stable isotopes have among the lowest binding energies per nucleon of all stable nuclides. Due to this nuclear instability, lithium is less abundant in the solar system than 25 of the first 32 chemical elements [30].

Resources and reserves

An important frequent shortcoming in the discussion on availability of lithium is the lack of proper terminology and standardized concepts for assessing the available amounts of lithium. Published studies talk about “reserves”, “resources”, “recoverable resources”, “broad-based reserves”, “in-situ resources”, and “reserve base”.

A wide range of reporting systems minerals exist, such as NI 43-101, USGS, Crirsco, SAMREC and the JORC code, and further discussion and references concerning this can be found in Vikström [31]. Definitions and classifications used are often similar, but not always consistent, adding to the confusion when aggregating data. Consistent definitions may be used in individual studies, but frequently figures from different methodologies are combined as there is no universal and standardized framework. In essence, published literature is a jumble of inconsistent figures. If one does not know what the numbers really mean, they are not simply useless – they are worse, since they tend to mislead.

Broadly speaking, resources are generally defined as the geologically assured quantity that is available for exploitation, while reserves are the quantity that is exploitable with current technical and socioeconomic conditions. The reserves are what are important for production, while resources are largely an academic figure with little relevance for real supply. For example, usually less than one tenth of the coal resources are considered economically recoverable [32, 33]. Kesler et al. [21] stress that available resources needs to be converted into reserves before they can be produced and used by society. Still, some analysts seemingly use the terms ‘resources’ and ‘reserves’ synonymously.

It should be noted that the actual reserves are dynamic and vary depending on many factors such as the available technology, economic demand, political issues and social factors. Technological improvements may increase reserves by opening new deposit types for exploitation or by lowering production costs. Deposits that have been mined for some time can increase or decrease their reserves due to difficulties with determining the ore grade and tonnage in advance [34]. Depletion and decreasing concentrations may increase recovery costs, thus lowering reserves. Declining demand and prices may also reduce reserves, while rising prices or demand may increase them. Political decisions, legal issues or environmental policies may prohibit exploitation of certain deposits, despite the fact significant resources may be available.

For lithium, resource/reserve classifications were typically developed for solid ore deposits. However, brine – presently the main lithium source – is a fluid and commonly used definitions can be difficult to apply due to pumping complications and varying concentrations.

Houston et al. [35] describes the problem in detail and suggest a change in NI 43-101 to account for these problems. If better standards were available for brines then estimations could be more reliable and accurate, as discussed in Kushnir and Sandén [18].

Environmental aspects and policy changes can also significantly influence recoverability. Introduction of clean air requirements and public resistance to surface mining in the USA played a major role in the decreasing coal reserves [33].

It is entirely possible that public outcries against surface mining or concerns for the environment in lithium producing will lead to restrictions that affect the reserves. As an example, the water consumption of brine production is very high and Tahil [19] estimates that brine operations consume 65% of the fresh water in the Salar de Atacama region. [ The Atacama only gets 0.6 inches of rain a year ]

Regarding future developments of recoverability, Fasel and Tran [36] monotonously assumes that increasing lithium demand will result in more reserves being found as prices rise. So called cumulative availability curves are sometimes used to estimate how reserves will change with changing prices, displaying the estimated amount of resource against the average unit cost ranked from lowest to highest cost. This method is used by Yaksic and Tilton [14] to address lithium availability. This concept has its merits for describing theoretical availability, but the fact that the concept is based on average cost, not marginal cost, has been described as a major weakness, making cumulative availability curves disregard the real cost structure and has little – if any – relevance for future price and production rate [37].

Production and occurrence of lithium

The high reactivity of lithium makes it geochemistry complex and interesting. Lithium-minerals are generally formed in magmatic processes. The small ionic size makes it difficult for lithium to be included in early stages of mineral crystallization, and resultantly lithium remains in the molten parts where it gets enriched until it can be solidified in the final stages [38].

At present, over 120 lithium-containing minerals are known, but few of them contain high concentrations or are frequently occurring. Lithium can also be found in naturally occurring salt solutions as brines in dry salt lake environments. Compared to the fairly large number of lithium mineral and brine deposits, few of them are of actual or potential commercial value. Many are very small, while others are too low in grade [39]. This chapter will briefly review the properties of those deposits and present a compilation of the known deposits.

Lithium mineral deposits

Lithium extraction from minerals is primarily done with minerals occurring in pegmatite formations. However, pegmatite is rather challenging to exploit due to its hardness in conjunction with generally problematic access to the belt-like deposits they usually occur in. Table 1 describes some typical lithium-bearing minerals and their characteristics. Australia is currently the world’s largest producer of lithium from minerals, mainly from spodumene [39]. Petalite is commonly used for glass manufacture due to its high iron content, while lepidolite was earlier used as a lithium source but presently has lost its importance due to high fluorine content. Exploitation must generally be tailor-made for a certain mineral as they differ quite significantly in chemical composition, hardness and other properties[13]. Table 2 presents some mineral deposits and their properties.

Recovery rates for mining typically range from 60 to 70%, although significant treatment is required for transforming the produced Li into a marketable form. For example, [40, 41] describe how lithium are produced from spodumene. The costs of acid, soda ash, and energy are a very significant part of the total production cost but may be partially alleviated by the market demand for the sodium sulphate by-products.

Lithium brine deposits

Lithium can also be found in salt lake brines that have high concentrations of mineral salts. Such brines can be reachable directly from the surface or deep underground in saline expanses located in very dry regions that allow salts to persist. High concentration lithium brine is mainly found in high altitude locations such as the Andes and south-western China. Chile, the world largest lithium producer, derives most of the production from brines located at the large salt flat of Salar de Atacama.

Lithium has similar ionic properties as magnesium since their ionic size is nearly identical; making is difficult to separate lithium from magnesium. A low Mg/Li ratio in brine means that it is easier, and therefore more economical to extract lithium.

Lithium Market Research SISThe ratio differs significant at currently producing brine deposits and range from less than 1 to over 30 [14]. The lithium concentration in known brine deposits is usually quite low and range from 0.017–0.15% with significant variability among the known deposits in the world (Table 3).

Exploitation of lithium brines starts with the brine being pumped from the ground into evaporation ponds. The actual evaporation is enabled by incoming solar radiation, so it is desirable for the operation to be located in sunny areas with low annual precipitation rate. The net evaporation rate determines the area of the required ponds [42].

It can easily take between one and two years before the final product is ready to be used, and even longer in cold and rainy areas.

The long timescales required for production can make brine deposits ill fit for sudden changes in demand. Table 3. Properties of known brine deposits in the world.

Lithium from sea water

The world’s oceans contain a wide number of metals, such as gold, lithium or uranium, dispersed at low concentrations. The mass of the world’s oceans is approximately 1.35*1012 Mt [47], making vast amounts of theoretical resources seemingly available. Eckhardt [48] and Fasel and Tran [36] announce that more than 2,000,000 Mt lithium is available from the seas, essentially making it an “unlimited” source given its geological abundance. Tahil [20] also notes that oceans have been proclaimed as an unlimited Li-source since the 1970s.

The world’s oceans and some highly saline lakes do in fact contain very large quantities of lithium, but if it will become practical and economical to produce lithium from this source is highly questionable.

For example, consider gold in sea water – in total nearly 7,000,000 Mt. This is an enormous amount compared to the cumulative world production of 0.17 Mt accumulated since the dawn of civilization [49]. There are also several technical options available for gold extraction. However, the average gold concentration range from <0.001 to 0.005 ppb [50]. This means that one km3 of sea water would give only 5.5 kg of gold. The gold is simply too dilute to be viable for commercial extraction and it is not surprising that all attempts to achieve success – including those of the Nobel laureate Fritz Haber – has failed to date.

Average lithium concentration in the oceans has been estimated to 0.17 ppm [14, 36]. Kushnir and Sandén [18] argue that it is theoretically possible to use a wide range of advanced technologies to extract lithium from seawater – just like the case for gold. However, no convincing methods have been demonstrated this far. A small scale Japanese experiment managed to produce 750 g of lithium metal from processing 4,200 m3 water with a recovery efficiency of 19.7% [36]. This approach has been described in more detail by others [51–53].

Grosjean et al. [13] points to the fact that even after decades of improvement, recovery from seawater is still more than 10–30 times more costly than production from pegmatites and brines. It is evident that huge quantities of water would have to be processed to produce any significant amounts of lithium. Bardi [54] presents theoretical calculations on this, stating that a production volume of lithium comparable to present world production (~25 kt annually) would require 1.5*103 TWh of electrical energy for pumping through separation membranes in addition to colossal volumes of seawater. Furthermore, Tahil [20] estimated that a seawater processing flow equivalent to the average discharge of the River Nile – 300,000,000 m3/day or over 22 times the global petroleum industry flow of 85 million barrels per day – would only give 62 tons of lithium per day or roughly 20 kt per year. Furthermore, a significant amount of fresh water and hydrochloric acid will be required to flush out unwanted minerals (Mg, K, etc.) and extract lithium from the adsorption columns [20].

In summary, extraction from seawater appears not feasible and not something that should be considered viable in practice, at least not in the near future.

Estimated lithium availability

From data compilation and analysis of 112 deposits, this study concludes that 15 Mt areImage result for lithium reasonable as a reference case for the global reserves in the near and medium term. 30 Mt is seen as a high case estimate for available lithium reserves and this number is also found in the upper range in literature. These two estimates are used as constraints in the models of future production in this study.

Estimates on world reserves and resources vary significantly among published studies. One main reason for this is likely the fact that different deposits, as well as different number of deposits, are aggregated in different studies. Many studies, such as the ones presented by the USGS, do not give explicitly state the number of deposits included and just presents aggregated figures on a national level. Even when the number and which deposits that have been used are specified, analysts can arrive to wide different estimates (Table 5). It should be noted that a trend towards increasing reserves and resources with time can generally be found, in particularly in USGS assessments. Early reports, such as Evans [56] or USGS [59], excluded several countries from the reserve estimates due to a lack of available information. This was mitigated in USGS [73] when reserves estimates for Argentina, Australia, and Chile have been revised based on new information from governmental and industry sources. However, there are still relatively few assessments on reserves, in particular for Russia, and it is concluded that much future work is required to handle this shortcoming. Gruber et al. [16] noted that 83% of global lithium resources can be found in six brine, two pegmatite and two sedimentary deposits. From our compilation, it can also be found that the distribution of global lithium reserves and resources are very uneven.

Three quarters of everything can typically be found in the ten largest deposits (Figure 1 and 2). USGS [12] pinpoint that 85% of the global reserves are situated in Chile and China (Figure 3) and that Chile and Australia accounted for 70 % of the world production of 28,100 tonnes in 2011 [12]. From Table 2 and 3, one can note a significant spread in estimated reserves and resources for the deposits. This divergence is much smaller for minerals (5.6–8.2 Mt) than for brines (6.5– 29.4 Mt), probably resulting from the difficulty associated with estimating brine accumulations consistently. Evans [75] also points to the problem of using these frameworks on brine deposits, which are fundamentally different from solid ores. Table 5. Comparison of published lithium assessments.

Recycling

One thing that may or may not have a large implication for future production is recycling. The projections presented in the production model of this study describe production of lithium from virgin materials. The total production of lithium could potentially increase significantly if high rates of recycling were implemented of the used lithium, which is mentioned in many studies.

USGS [12] state that recycling of lithium has been insignificant historically, but that it is increasing as the use of lithium for batteries are growing. However, the recycling of lithium from batteries is still more or less non-existent, with a collection rate of used Li-ion batteries of only about 3% [93]. When the Li-ion batteries are in fact recycled, it is usually not the lithium that is recycled, but other more precious metals such as cobalt [18].

If this will change in the future is uncertain and highly dependent on future metal prices, but it is still commonly argued for and assumed that the recycling of lithium will grow significantly, very soon. Goonan [94] claims that recycling rates will increase from vehicle batteries in vehicles since such recycling systems already exist for lead-acid batteries. Kushnir and Sandén [18] argue that large automotive batteries will be technically easier to recycle than smaller batteries and also claims that economies of scale will emerge when the use for batteries for vehicles increase. According to the IEA [95], full recycling systems are projected to be in place sometime between 2020 and 2030. Similar assumptions are made by more or less all studies dealing with future lithium production and use for electric vehicles and Kushnir and Sandén [18] state that it is commonly assumed that recycling will take place, enabling recycled lithium to make up for a big part of the demand but also conclude that the future recycling rate is highly uncertain.

There are several reasons to question the probability of high recycling shares for Li-ion batteries. Kushnir and Sandén [18] state that lithium recycling economy is currently not good and claims that the economic conditions could decrease even more in the future. Sullivan and Gaines [96] argue that the Li-ion battery chemistry is complex and still evolving, thus making it difficult for the industry to develop profitable pathways. Georgi-Maschler [93] highlight that two established recycling processes exist for recycling Li-ion batteries, but one of them lose most of the lithium in the process of recovering the other valuable metals. Ziemann et al. [97] states that lithium recovery from rechargeable batteries is not efficient at present time, mainly due to the low lithium content of around 2% and the rather low price of lithium.

In this study we choose not to include recycling in the projected future supply for several reasons. In a short perspective, looking towards 2015-2020, it cannot be considered likely that any considerable amount of lithium will be recycled from batteries since it is currently not economical to do so and no proven methods to do it on a large scale industrial level appear to exist. If it becomes economical to recycle lithium from batteries it will take time to build the capacity for the recycling to take place. Also, the battery lifetime is often projected to be 10 years or more, and to expect any significant amounts of lithium to be recycled within this period of time is simply not realistic for that reason either.

The recycling capacity is expected to be far from reaching significant levels before 2025 according to Wanger [92]. It is also important to separate the recycling rates of products to the recycled content in new products. Even if a percentage of the product is recycled at the end of the life cycle, this is no guarantee that the use of recycled content in new products will be as high. The use of Li-ion batteries is projected to grow fast. If the growth happens linearly, and high recycling rates are accomplished, recycling could start constituting a large part of the lithium demand, but if the growth happens exponentially, recycling can never keep up with the growth that has occurred during the 10 years lag during the battery lifetime. In a longer time perspective, the inclusion of recycling could be argued for with expected technological refinement, but certainties regarding technology development are highly uncertain. Still, most studies include recycling as a major part of future lithium production, which can have very large implications on the results and conclusions drawn. Kushnir and Sandén [18] suggest that an 80% lithium recovery rate is achievable over a medium time frame. The scenarios in Gruber et al. [16], assumes recycling participation rates of 90 %, 96% and 100%. In their scenario using the highest assumed recycling, the quantities of lithium needed to be mined are decreased to only about 37% of the demand. Wanger [92] looks at a shorter time perspective and estimates that a 40% or 100% recycling rate would reduce the lithium consumption with 10% or 25% respectively by 2030. Mohr et al. [15] assume that the recycling rate starts at 0%, approaching a limit of 80%, resulting in recycled lithium making up significant parts of production, but only several decades into the future. IEA [95] projects that full recycling systems will be in place around 2020–2030.

The impact of assumed recycling rates can indeed be very significant, and the use of this should be handled with care and be well motivated.

Future demand for lithium

To estimate whether the projected future production levels will be sufficient, it isImage result for lithiuminteresting to compare possible production levels with potential future demand. The use of lithium is currently dominated by use for ceramics and glass closely followed by batteries. The current lithium demand for different markets can be seen in Figure 7. USGS [12] state that the lithium use in batteries have grown significantly in recent years as the use of lithium batteries in portable electronics have become increasingly common. Figure 7 (Ceramics and glass 29%, Batteries 27%, Other uses 16%, Lubrication greases 12%, Continuous casting 5%, Air treatment 4%, Polymers 3%, Primary aluminum production 2%, Pharmaceuticals 2%).

Global lithium demand for different end-use markets. Source: USGS [12] USGS [12] state that the total lithium consumption in 2011 was between 22,500 and 24,500 tonnes. This is often projected to grow, especially as the use of Li-ion batteries for electric cars could potentially increase demand significantly. This study presents a simple example of possible future demand of lithium, assuming a constant demand for other uses and demand for electric cars to grow according to a scenario of future sales of

electric cars. The current car fleet consists of about 600 million passenger cars. The sale of new passenger cars in 2011 was about 60 million cars [98]. This existing vehicle park is almost entirely dependent on fossil fuels, primarily gasoline and diesel, but also natural gas to a smaller extent. Increasing oil prices, concerns about a possible peak in oil production and problems with anthropogenic global warming makes it desirable to move away from fossil energy dependence. As a mitigation and pathway to a fossil-fuel free mobility, cars running partially or totally on electrical energy are commonly proposed. This includes electric vehicles (EVs), hybrid vehicles (HEVs) and PHEVs (plug-in hybrid vehicles), all on the verge of large-scale commercialization and implementation. IEA [99] concluded that a total of 1.5 million hybrid and electric vehicles had been sold worldwide between the year 2000 and 2010.

Both the expected number of cars as well as the amount of lithium required per vehicle is important. As can be seen from Table 9, the estimates of lithium demand for PEHV and EVs differ significantly between studies. Also, some studies do not differentiate between different technical options and only gives a single Li-consumption estimate for an “electric vehicle”, for instance the 3 kg/car found by Mohr et al. [15]. The mean values from Table 9 are found to be 4.9 kg for an EV and 1.9 kg for a PHEV.

As the battery size determines the vehicles range, it is likely that the range will continue to increase in the future, which could increase the lithium demand. On the other hand, it is also reasonable to assume that the technology will improve, thus reducing the lithium requirements. In this study a lithium demand of 160 g Li/kWh is assumed, an assumption discussed in detail by Kushnir and Sandén [18]. It is then assumed that typical batteries capacities will be 9 kWh in a PHEV and 25 kWh in an EV. This gives a resulting lithium requirement of 1.4 kg for a PHEV and 4 kg for an EV, which is used as an estimate in this study. Many current electrified cars have a lower capacity than 24 kWh, but to become more attractive to consumers the range of the vehicles will likely have to increase, creating a need for larger batteries [104]. It should be added that the values used are at the lower end compared to other assessments (Table 9) and should most likely not be seen as overestimates future lithium requirements.

Figure 8 shows the span of the different production forecasts up until 2050 made in this study, together with an estimated demand based on the demand staying constant on the high estimate of 2010– 2011, adding an estimated demand created by the electric car projections done by IEA [101]. This is a very simplistic estimation future demand, but compared to the production projections it indicates that lithium availability should not be automatically disregarded as a potential issue for future electric car production. The amount of electric cars could very well be smaller or larger that this scenario, but the scenario used does not assume a complete electrification of the car fleet by 2050 and such scenarios would mean even larger demand of lithium. It is likely that lithium demand for other uses will also grow in the coming decades, why total demand might increase more that indicated here. This study does not attempt to estimate the evolution of demand for other uses, and the demand estimate for other uses can be considered a conservative one. Figure 8. The total lithium demand of a constant current lithium demand combined with growth of electric vehicles according to IEA’s blue map scenario [101] assuming a demand for 1.4 kg of lithium per PHEV and 4.0 kg per EV. The span of forecasted production levels range from the base case Gompertz model

Concluding discussion

Potential future production of lithium was modeled with three different production curves. In a short perspective, until 2015–2020, the three models do not differ much, but in the longer perspective the Richards and Logistic curves show a growth at a vastly higher pace than the Gompertz curve. The Richards model gives the best fit to the historic data, and lies in between the other two and might be the most likely development. A faster growth than the logistic model cannot be ruled out, but should be considered unlikely, since it usually mimics plausible free market exploitation [89]. Other factors, such as decreased lithium concentration in mined material, economics, political and environmental problems could also limit production.

It can be debated whether this kind of forecasting should be used for short term projections, and the actual production in coming years can very well differ from our models, but it does at least indicate that lithium availability could be a potential problem in the coming decades. In a longer time perspective up to 2050, the projected lithium demand for alternative vehicles far exceeds our most optimistic production prognoses.

If 100 million alternative vehicles, as projected in IEA [101] are produced annually using lithium battery technology, the lithium reserves would be exhausted in just a few years, even if the production could be cranked up faster than the models in this study. This indicates that it is important that other battery technologies should be investigated as well.

It should be added that these projections do not consider potential recycling of the lithium, which is discussed further earlier in this paper. On the other hand, it appears it is highly unlikely that recycling will become common as soon as 2020, while total demand appears to potentially rise over maximum production around that date. If, when, and to what extent recycling will take place is hard to predict, although it appears more likely that high recycling rates will take place in electric cars than other uses.

Much could change before 2050. The spread between the different production curves are much larger and it is hard to estimate what happens with technology over such a long time frame. However, the Blue Map Scenario would in fact create a demand of lithium that is higher than the peak production of the logistic curve for the standard case, and close to the peak production in the high URR case.

Improved efficiency can decrease the lithium demand in the batteries, but as Kushnir and Sandén [18] point out, there is a minimum amount of lithium required tied to the cell voltage and chemistry of the battery.

IEA [95] acknowledges that technologies that are not available today must be developed to reach the Blue Map scenarios and that technology development is uncertain. This does not quite coincide with other studies claiming that lithium availability will not be a problem for production of electric cars in the future.

It is also possible that other uses will raise the demand for lithium even further. One industry that in a longer time perspective could potentially increase the demand for lithium is fusion, where lithium is used to breed tritium in the reactors. If fusion were commercialized, which currently seems highly uncertain, it would demand large volumes of lithium [36].

Further problems with the lithium industry are that the production and reserves are situated in a few countries (USGS [12] in Mt: Chile 7.5, China 3.5, Australia 0.97, Argentina 0.85, Other 0.135]. One can also note that most of the lithium is concentrated to a fairly small amount of deposits, nearly 50% of both reserves and resources can be found in Salar de Atacama alone. Kesler et al. [21] note that Argentina, Bolivia, Chile and China hold 70% of the brine deposits. Grosjean et al. [13] even points to the ABC triangle (i.e. Argentina, Bolivia and Chile) and its control of well over 40% of the world resources and raises concern for resource nationalism and monopolistic behavior. Even though Bolivia has large resources, there are many political and technical problems, such as transportation and limited amount of available fresh water, in need of solutions [18].

Regardless of global resource size, the high concentration of reserves and production to very few countries is not something that bode well for future supplies. The world is currently largely dependent on OPEC for oil, and that creates possibilities of political conflicts. The lithium reserves are situated in mainly two countries. It could be considered problematic for countries like the US to be dependent on Bolivia, Chile and Argentina for political reasons [105]. Abell and Oppenheimer [105] discuss the absurdity in switching from dependence to dependence since resources are finite. Also, Kushnir and Sandén [18] discusses the problems with being dependent on a few producers, if a problem unexpectedly occurs at the production site it may not be possible to continue the production and the demand cannot be satisfied.

Final remarks

Although there are quite a few uncertainties with the projected production of lithium and demand for lithium for electric vehicles, this study indicates that the possible lithium production could be a limiting factor for the number of electric vehicles that can be produced, and how fast they can be produced. If large parts of the car fleet will run on electricity and rely on lithium based batteries in the coming decades, it is possible, and maybe even likely, that lithium availability will be a limiting factor.

To decrease the impact of this, as much lithium as possible must be recycled and possibly other battery technologies not relying on lithium needs to be developed. It is not certain how big the recoverable reserves of lithium are in the world and estimations in different studies differ significantly. Especially the estimations for brine need to be further investigated. Some estimates include production from seawater, making the reserves more or less infinitely large. We suggest that it is very unlikely that seawater or lakes will become a practical and economic source of lithium, mainly due to the high Mg/Li ratio and low concentrations if lithium, meaning that large quantities of water would have to be processed. Until otherwise is proved lithium reserves from seawater and lakes should not be included in the reserve estimations. Although the reserve estimates differ, this appears to have marginal impact on resulting projections of production, especially in a shorter time perspective. What are limiting are not the estimated reserves, but likely maximum annual production, which is often missed in similar studies.

If electric vehicles with li-ion batteries will be used to a very high extent, there are other problems to account for. Instead of being dependent on oil we could become dependent on lithium if li-ion batteries, with lithium reserves mainly located in two countries. It is important to plan for this to avoid bottlenecks or unnecessarily high prices. Lithium is a finite resource and the production cannot be infinitely large due to geological, technical and economical restraints. The concentration of lithium metal appears to be decreasing, which could make it more expensive and difficult to extract the lithium in the future. To enable a transition towards a car fleet based on electrical energy, other types of batteries should also be considered and a continued development of battery types using less lithium and/or other metals are encouraged. High recycling rates should also be aimed for if possible and continued investigations of recoverable resources and possible production of lithium are called for. Acknowledgements We would like to thank Steve Mohr for helpful comments and ideas. Sergey Yachenkov has our sincerest appreciation for providing assistance with translation of Russian material.
